5-driver, 2-1/2-way acoustic suspension LCR on-wall with option to sit center speaker on a table or shelf.
DESIGN
5-driver, 2-1/2-way acoustic suspension LCR on-wall with option to sit center speaker on a table or shelf with supports included
CROSSOVER
2nd-order electro-acoustic at 2.1 kHz; 2nd-order electro-acoustic at 500 Hz (bass drivers)
HIGH FREQUENCY DRIVER
Three 25-mm (1 in) S-PAL™ dome tweeters, ferro-fluid damped and cooled
FREQUENCY RESPONSE ON-AXIS
±2dB from 115 Hz – 20 kHz
FREQUENCY RESPONSE 30° OFF-AXIS
±2dB from 115 Hz – 15 kHz
MID/BASS FREQUENCY DRIVER
102-mm (3-1/2 in) mineral-filled polypropylene cone, 25-mm (1 in) high-temperature voice coil, advanced motor structures with oversized ferrite magnets
LOW FREQUENCY DRIVER
Two 102-mm (3-1/2 in) mineral-filled polypropylene cones, 25-mm (1 in) high-temperature voice coils, advanced motor structures and oversized ferrite magnets
SENSITIVITY ROOM / ANECHOIC
95 dB / 92 dB
LOW FREQUENCY EXTENSION
75 Hz (DIN)
SUITABLE AMPLIFIER POWER RANGE
15 – 200 watts
MAXIMUM INPUT POWER
100 watts
IMPEDANCE
Compatible with 8 ohms
FINISHES
Black Gloss
DIMENSIONS HXWXD
26.375″ × 6.3125″ × 4.0625″ (67.0cm × 16.0cm × 10.3cm)
WEIGHT
12.8 lbs. (5.8 kg)
